300DD-90SS - Dixon Type DD 90° Elbow Coupler x Coupler

Designed for use with liquids, consult Dixon for specific recommendations

Produced as a welded fabrication

• To make a connection, simply slide the adapter into the coupler and with normal hand pressure, press the cam levers down.
• Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.

• Under no circumstances should cam and groove couplings be used for compressed air or steam service!
• Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F (21°C) with a standard seal installed. For use at elevated temperature or other unusual operating conditions, consult Dixon.

Produced to interchange with all product produced to Commercial Item Description A-A-59326D
