Dixon
2AF1-B - A-Series Pneumatic Female Threaded Coupler
(No reviews yet)
Write a Review
- SKU:
- 2AF1-B
- Availability:
- Usually Ships Within 24 Hours
- Weight:
- 0.17 LBS
*Images are for visual reference only.
Description
Details
Applications
A series couplers are intended for use in compressed air service where the convenience of one hand operation and a compact profile is desired.
Compatibility & Interchange Data
Proprietary Astronautics
Construction
- Machined components are manufactured using solid bar stock.
- Stainless steel balls, retaining rings and springs maximize corrosion resistance and extend service life.
- Couplers are constructed of brass with steel valve as standard
- Steel componentry is plated using ROHS Compliant Trivalent Chrome.
Safety Notes
Pressure rating given at ambient temperature 70°F (21°C).
Specifications
- Rated pressure for connected Brass Coupler & Brass Plug: 500 PSI (35 bar) Maximum Working and 6,500 PSI (450 bar) Burst
- Rated pressure for connected Brass Coupler & Steel Plug: 1,000 PSI (70 bar) Maximum Working and 8,000 PSI (550 bar) Burst
WARNING: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
